| product name | AccurioPress 6136 | Accurio Press 6120 | AccurioPress 6136P | |
|---|---|---|---|---|
| format | console | |||
| Reading resolution | 600 dpi × 600 dpi | - | ||
| Write resolution | 1200 dpi × 1200 dpi | |||
| tone | 256 gradations | |||
| Memory capacity | 16 GB | |||
| HDD | 1 TB × 2 | |||
| Copy original | Sheets, books, three-dimensional objects (weight up to 6.8 kg) | - | ||
| Maximum document size | A3 | - | ||
| Maximum printing area | 313.9 x 483 mm | |||
| size of paper | 3At the time of installing PF – 710: Undefined pattern paper (maximum 324× 483 mm, minimum 95 × ( minimum ) × 100 mm) Paper size (maximum 324× 463 mm , minimum 182 × 139 mm) When loaded with PF – 710 SRA 3, SRA 4, A 3, B 4, A 4, B 5, 133 mm) | |||
| Image missing width | Tip: 3 mm or less, rear end: 2 mm or less, front / back side 2 mm or less | |||
| Warm up time | 420 seconds or less (room temperature 20° C, rated power supply) | |||
| First Copy * 1 / Print Time | 2.7 seconds or less | 2.8 seconds or less | 2.7 seconds or less | |
| Continuous copy (print) speed * 2 | 136 sheets / minute (A4 horizontal) 78 sheets / minute (A3) | 120 sheets / minute (A4 horizontal) 70 sheets / minute (A3) | 136 sheets / minute (A4 horizontal) 78 sheets / minute (A3) | |
| Copy magnification | Equal magnification | 1: 1 ± 0.5% or less | - | |
| Expansion | 1: 1.154 / 1.224 / 1.414 / 2.000 | - | ||
| Shrinking | 1: 0.866 / 0.816 / 0.707 / 0.500 | - | ||
| Fixed optional | three types can be set | - | ||
| zoom | 25% to 400% (It can be set in 0.1% unit) | - | ||
| Paper feed metdod / paper feed amount | 2 step tray: (1,500 sheets × 2 steps) 80 g / m 2 paper | |||
| Corresponding paper basis weight | Standard: 40 gsm to 300 gsm (Limitations to paper types apply) PF-706 and middle tray of PF-709 : 40 gsm to 350 gsm (Limitations to paper types apply)*3 | |||
| Continuous copy (print) number | 1 to 9,999 sheets | - | ||
| Duplex copy (print) | Postcard amorphous paper (maximum: 324× 483 mm, minimum: 95 × 133 mm) Supported paper basis weight: 40 to 300 g / m2 SRA 3, SRA 4, A 3, B 4, A 4, B 5, | |||
| Power supply | Single phase 3 wire type AC 200 V 25 A (50 Hz / 60 Hz) | |||
| Maximum power consumption | 4.0 kW (Device system value other than option equipped with dedicated power cord) | |||
| Size (width × deptd × height) | 990 × 910 × 1,200 mm (main body + ADF, not including operation section) | 990 × 910 × 1,020 mm (Only the main unit, not including the operation unit) | ||
| Mechanical installation dimensions | Secure work space of more tdan 200 mm from the back duct and more tdan 100 mm on the left and right when 631 mm or more (when the main body ADU gantry is pulled out) on the front of the machine | |||
| mass | About 369 kg | About 345 kg | ||
| Types of document feeder | Automatic two-sided document feeder | |
|---|---|---|
| Type of manuscript | Plain paper / special paper (single-sided original: 35 to 210 g/m 2 , double-sided mixed mixed original: 50 to 128 g / m 2 ) | |
| Original size | Up to 297 x 431.8 mm | |
| Number of sheets stacked | 300 sheets (80 g / m 2 ) Same series, different series mixed original | |
| Document reading speed | When copying (600 dpi) | Full color: Single side 75 pages / minute Botd sides 150 pages / minute (A4 horizontal) Monochrome: Single side 80 pages / minute Double side 160 pages / minute (A4 horizontal) |
| During scanning (300 dpi) | Full color / monochrome: Single side 120 pages / minute Double side 240 pages / minute (A4 horizontal) | |
| Power supply | Supplied from main unit | |
| Size (width × deptd × height) | 618 × 575 × 180 mm (excluding paper feeding tray) | |
| mass | Approximately 15 kg | |
| format | Built-in type | |
|---|---|---|
| Continuous printing speed | It conforms to main body specification | |
| Resolution | 1200 dpi × 1200 dpi / 600 dpi × 600 dpi | |
| Memory | 16 GB | |
| Page description language | PCL 5e / 6, Adobe PostScript 3 (PS 3020), PDF direct print (PDF Ver 1.7) TIFF direct print (conforming to TIFF Ver 6), PPML (Ver 2.2), APPE 4.2* 1 | |
| Built-in font | PCL | Japanese 4 typeface (HG Gothic B, HG Ming Dynasty L, HGP Gothic B, HGP Mincho L) European 80 Font |
| PS3 | Japanese 2 typeface (middle Gothic BBB, Ryumin L-KL) European text 136 typeface | |
| Supported protocol | TCP / IP, IPX / SPX, NetBEUI, IPP, WSD, Bonjour, SMB | |
| Supported OS | PCL | 7 Windows ※ 2 / 8.1 ※ 2 /10 ※ 2 Windows Server 2008※ 2 / 2008R2 / 2012 ※ 2 / 2012R2 / 2016 |
| PS | 7 Windows ※ 2 / 8.1 ※ 2 /10 ※ 2 Windows Server 2008※ 2 / 2008R2 / 2012 ※ 2 / 2012R2 / 2016 | |
| PS-Plug-in | 7 Windows ※ 2 / 8.1 ※ 2 /10 ※ 2 Windows Server 2008※ 2 / 2008R2 / 2012 ※ 2 / 2012R2 / 2016 Mac OS X 10.8, X 10.9, X 10.10, X 10.11, X 10.12, X 10.13 | |
| interface | 10Base-T / 100Base-TX / 1000Base-T, USB2.0 (Hi-Speed) | |
| format | Color scanner |
|---|---|
| Reading resolution | 200 × 200 dpi, 300 × 300 dpi, 400 × 400 dpi, 600 × 600 dpi |
| Document reading speed (A4 horizontal) | Single-sided (color / monochrome): 120 pages / min (300 dpi) Double-sided simultaneous reading (color / monochrome): 240 pages / min (300 dpi) |
| interface | Ethernet 10Base-T / 100Base-TX / 1000Base-T |
| Supported protocol | TCP / IP (FTP, SMB, SMTP, WebDAV) (IPv4 / IPv6) |
| Output format | TIFF, JPEG, PDF, compact PDF, XPS, encrypted PDF, PDF / A |
| Supported OS * 1 | 7 Windows *2 / 8.1 ※ 2 /10 ※ 2 |
| function | Overlap inversion function |
|---|---|
| Supported paper size | 95 × 133 to 324 × 483 mm |
| tdrough transport function | Applicable paper basis weight: 40 to 350 g / m 2 Paper type: plain paper, woodfree paper, coated paper, recycled paper, envelope, embossed and Lesaac paper |
| Inversion function | Applicable paper basis weight: 40 to 300 g / m 2 Paper type: plain paper, high-quality paper, coated paper, recycled paper, embossed • LEresac paper |
| Overlay function | Applicable paper basis weight: 40 to 216 g / m 2 Paper type: plain paper, high quality paper, coated paper, recycled paper, Emboss • Lesail paper |
| Power supply | Supplied from main unit |
| Maximum power consumption | 68 W or less |
| Size (width × deptd × height) | 410 × 723 × 1,020 mm |
| mass | Approximately 36 kg |
| function | Relay transport unit with sheet cooling / decurler function |
|---|---|
| Wearable options | Sheet humidification kit HM – 103 |
| Power supply | AC 100 – 240 VAC 50/60 Hz |
| Maximum power consumption | 700 W or less (including RU / HM / latter connection option) |
| Size (width × deptd × height) | 410 × 782.7 × 1, 135 mm |
| Mass | Approximately 80 kg |
Our remote diagnosis system CSRC is an advanced support network using communication lines. In addition to instantly notifying our service management system of failures by any chance, we have an alarm information function that minimizes downtime of machines, and we are pursuing customers’ maximum satisfaction. Also, you can check the monthly counter check etc without having to bother your hands. Konica Minolta considers support system & aftercare on a higher rank if it is one of high performance.
